Projects

Panel builds, controls upgrades, and system design work from plants across the Mid-South.

01

Pumping Control Upgrade

Old panel replaced with new PLC, HMI, and pump controls
Before
Pumping Control Upgrade - Old 1 Pumping Control Upgrade - Old 2
After
Pumping Control Upgrade - New 1 Pumping Control Upgrade - New 2
02

PLC Upgrade

Legacy processors migrated to current platforms, with drawings for construction
PLC Upgrade 01 PLC Upgrade 02
03

Enclosure & Control Panel Builds

Drives, servo, and I/O layouts wired and labeled to print
Enclosure - Control 1 Enclosure - Control 2 Enclosure - Control 3
04

Machine Controls Upgrade

Existing operator stations and cabinets assessed before replacement
Machine Controls Upgrade - Old 1 Machine Controls Upgrade - Old 2
05

Cotton Gin

Gin stands, module feeder, and stand-alone temperature control
Cotton Gin 1 Cotton Gin Module Feeder 1 Temperature Control Stand-Alone 1 Temperature Control Stand-Alone 2
06

Material Handling

Conveyor and sortation device layouts and controls
Material Handling 2
07

Control System Design & Testing

Panels built and programs tested on the bench before they ship
Control System Design and Testing
